● INTRODUCTION
- This is a product of DTDAuto Vietnam.
- Equipment is designed specially for vocational schools where trainees are taught both theory and practice of the electronic fuel injection system in OBD-II / CAN-compliant vehicles.
- Model DIAG-OBD-II-07 is modern perfect training equipment providing all basic elements in technique training such as: Listening, Watching and Acting with online simulation, tests, and professional fault diagnosis by using a computer.
- Construction of the system is built visually on the based of real parts of the system of multi-point fuel injection
& electronic ignition in Toyota vehicles from 2005 up to now.
- Connect online to DTD-Code (a computer-software) to display current sensor parameters, read and clear faults with the standard OBD-II.
- Designed with the German standard of training equipment
● TECHNICAL FEATURES
- Circuit diagram is printed on the board
- The Intake-air system uses an Air-pump
- All systems work as if they did in real vehicles
- Connected to the computer by USB port
● BASIC CONSTRUCTION
- 01 ECU of 1NZ-FE or 1ZZ-FR engine (Made in Japan)
- 01 knock sensor (Made in Japan)
- 01 Oxygen sensor (Made in Japan)
- 01 Coolant temperature sensor (Made in Japan)
- 01 Crankshaft position sensor (Made in Japan)
- 01 Camshaft position sensor (Made in Japan)
- 01 Throttle position sensor (Made in Japan)
- 01 Intake flow sensor (Made in Japan)
- 01 ISC valve (Made in Japan)
- 01 VVT-i valve (Made in Japan)
- 01 OBD-II connector (Made in Japan)
- 01 Check Engine Light (Made in Vietnam)
- 01 Ignition key (Made in Vietnam)
- 04 Main injectors (Made in Japan)
- 04 Ignition plugs (Made in Japan)
- 01 Fuel filter (Made in Japan)
- 01 Fuel pump (Made in Japan)
- 01 Pressure meter (Made in Taiwan)
- Some relays, lights, switches and 01 speed-adjuster (Made in Japan)
- 01 computer & computer table (optional without quotation)
- 01 CDROM installation of software
- 01 Diagnostic tool (Made by DTDAuto)
- 01 12V Battery (optional without quotation)
- 01 Equipment board with mobile-wheels
- Documents
● COMPONENTS
- 01 visual-model with real parts of the electronic fuel injection system of the generation vehicles
- 01 USB for software installation of Electronic fuel injection system (DTDCODE, TOYOTA SCANNER)
- Reference documents and textbooks
- 12V/30A Battery (optional)
- Accessories cables
